HV747
2013 FAI-F3F World Cup, Lung Pan F3F, 24.58s World Record by Mr.O !
High Torque Servo for Airplane / Jet / Electric Plane
- 12 x 20 mm coreless motor, High efficient, More durable.
- 9mm VR, Ultrahigh-resolution.
- New type gear structure, Tiny backlash, High durable.
Torque (6.0V): 11.8 kg-cm / 163.9 oz-in
Torque (7.4V): 13.8 kg-cm / 191.6 oz-in
Torque (8.2V): 15 kg-cm / 208.3 oz-in
Speed: 0.17 s (6.0V) / 0.14 s (7.4V) / 0.13 s (8.2V)
Weight: 38.55 g (1.36 oz)
Dimension：35.5 x 15 x 28.5 mm
| SERVO SPECIFICATION | |
| Stall Torque (kg-cm) | 11.8 (6.0V) / 13.8 (7.4V) / 15 (8.2V) |
| Stall Torque (oz-in) | 163.9 (6.0V) / 191.6 (7.4V) / 208.3 (8.2V) |
| No-load Speed | 0.17 s (6.0V) / 0.14 s (7.4V) / 0.13 s (8.2V) |
| Stall Current | 2.3A (6.0V) / 2.8A (7.4V) / 3.1A (8.2V) |
| Working Voltage | 6.0V ~ 8.4V DC Volts |
| Working Frequency | 1520μs / 333Hz |
| Dead Band | 0.001 ms (Default) |
| Bearing | 2* Ball Bearing |
| Gear | Metal Alloy Gear |
| Motor | Coreless Motor |
| Wire Length | 29.5 cm |
Spencer Lisenby - Dynamic Soaring World Record 519mph
Servo inside
-MKS HV747 -MKS HV6130 -MKS HV9767
|
HV737 / HV747 Servo testing
|
Team Pilot - Nikos Kioroglou MKS HV737 / MKS HV747 inside |
$109.45
- Product Code: S0022002
- Availability: In Stock
- $109.45
- Ex Tax: $109.45
